Performance Parameters:
Product
Model No
SA-3A611208
Sensor
Main Board Sensor
Industrial Embedded Microprocessor
Operating System
Embedded LINUX operating system
System
Video Coding
H.264
Coding Resolution
8CH 1080P(1920×1080)
Video Frame
PAL:1~15FP/S;NTSC:1~15FP/S
Video Bit Rate
512Kbps-4096Kbps,Customize,Default to be 2048Kbps
Stream Type
Video Streaming
Double Stream
Support
Video Spec
Video Input
8CH BNC Port
Video output
1*CVBS,1* VGA ,1* HDMI
Audio Ports
Audio Input/Output
4CH RCA input 1CH RCA output
Audio Intercom
Audio input, output reuse
Recording Manage
Recording Mode
Automatic recording, Manual Recording, Motion Detection Recording, Alarm Recording
Playback
4CH 1080P 15fps Playback
Backup Mode
Mobile Hard Disk / U-Hard-Disk / Network
Network
Protocol
Support:PPPOE ,TCP/IP,UDP,RTP/RTSP,DHCP,DDNS,NTP etc.
IE Control
With WEB Server to modify configuration parameters and remote control IE
P2P Cloud
Support login via www.yunyis.com to meet One-Key Remote Control.
Mobile Remote
Support IOS, Android,Blackberry, Symbion, Software .
3G
support
WIFI
support
HDD
HDD Port
Support 1*SATA port( max 4TB,No e-SATA port).
Interface
Network/USB
100M E-internet Port ; 2PCS USB Port
